Product Description
| MODEL | Prime KW | Starting Method | Governor | High pressure | 50HZ | 60HZ | ||
| Type | pipe | Speed | Engine Model | Speed | Engine Model | |||
| r/min | r/min | |||||||
| CCFJ30Y-WZ | 30 | Electric&Air | electric | anti-explosion | 1500 | WP4CD66E200 | 1800 | WP4CD66E201 |
| CCFJ40Y-WZ | 40 | Electric&Air | electric | anti-explosion | 1500 | WP4CD66E200 | 1800 | WP4CD66E201 |
| CCFJ50Y-WZ | 50 | Electric&Air | electric | anti-explosion | 1500 | WP4CD66E200 | 1800 | WP4CD66E201 |
| CCFJ64Y-WZ | 64 | Electric&Air | electric | anti-explosion | 1500 | WP4CD100E200 | 1800 | WP4CD100E201 |
| CCFJ75Y-WZ | 75 | Electric&Air | electric | anti-explosion | 1500 | WP4CD100E200 | 1800 | WP4CD100E201 |
| CCFJ90Y-WZ | 90 | Electric&Air | electric | anti-explosion | 1500 | WP6CD132E200 | 1800 | WP6CD132E201 |
| CCFJ100Y-WZ | 100 | Electric&Air | electric | anti-explosion | 1500 | WP6CD132E200 | 1800 | WP6CD132E201 |
| CCFJ120Y-WZ | 120 | Electric&Air | electric | anti-explosion | 1500 | WP6CD152E200 | 1800 | WP6CD152E201 |
| CCFJ150Y-WY | 150 | Electric&Air | electric | anti-explosion | 1500 | WP10CD200E200 | 1800 | WP10CD200E201 |
| CCFJ180Y-WY | 180 | Electric&Air | electric | anti-explosion | 1500 | WP10CD238E200 | 1800 | WP10CD238E201 |
| CCFJ200Y-WY | 200 | Electric&Air | electric | anti-explosion | 1500 | WP10CD264E200 | 1800 | WP10CD264E201 |
| CCFJ250Y-WY | 250 | Electric&Air | electric | anti-explosion | 1500 | WP12CD317E200 | 1800 | WP12CD317E201 |
Widely used in inland and coastal waters, offshore market carriers, fishing boats, official boats, ships and other projects
Has a good technical performance indicators;
Compact, high power per liter;
DC24V DC insulation systems;
Fully meet the requirements of the "steel marine vessel construction norms", "steel ship classification rules", GB13032 "marine diesel generator sets, etc.;
Rated power: 30-250KW
Rated voltage: 400V;
The rated speed / rated frequency: 1500rpm/50Hz;
Rated power factor: 0.8 (lagging);
number of cylinders / Bore / Stroke:4/105*130m ----6/126*130mm;
Displacement 4.5L---11.596L;
Cooling: Closed radiator fan forced cooling;
The start-up mode: DC24V electric motor and air motor (spring motors);
Number of phases and connection: three-phase four-wire, star connection;
Excitation / regulator: Brushless / AVR automatically;
Diesel fuel consumption economy: ≤ 200g/kW · h;
Oil consumption: ≤ 1.1g/kW · h;
1.What is your warranty period?
Our warranty period is 1 year or 1200 working hours , whichever comes first(excluding damage to generator set spare parts due to incorrect manual operation)
2.Is your products the lowest price?
The price is based on the quality level and the order quantity.
We have different quality level products for buyers option.
3.What's your delivery time?
Our standard delivery time is 20 to 30 days. If you have urgent demand, the delivery time will be shortened as needed. If you have special requirements , the delivery time will be longer.
4.Can machines be customized?
Yes. Our machines can be customized according to the specific requirements of customers.
5.What are your terms of payment?
T/T 30% as deposit , 70% before delivery. Before you pay, we will show you pictures of the products and packaging.
