Basic Info.
Product Description
SDEC POWER GENERATORS
The operation of various applications and industries depends on SDEC generator sets. You can rely on SDEC Power to provide strong, flexible and fully integrated on-demand power supply or all-time power supply. In the global economy, all-weather power supply.
Diesel Generator Technical Data | |||
| Genset model | HT-60 | Prime Power (KW) | 60 |
| Rated frequency(Hz) | 50/60 | Prime Power (KVA) | 80 |
| Rated speed(Rpm) | 1500/1800 | Phase | 3 Phase |
| Voltage | 220/380V,230/400V, 240/415V,120/240V | N.W (KG) | 1200 |
| Rated Current | 108A | Silent Size (L*W*H) mm | 2300*750*1400mm |
| Diesel Engine Technical Data | |||
| Brand/Original | SDEC Shangchai | Type | Water Cool, Electric start |
| Engine Item No. | 4ZTAA4.1-G21 | Cylinder No. | 6 |
| Displacement (L) | 4.1 | Bore and Stoke (MM) | 105*118 |
| Prime Power (KW) | 64 | Fuel Consumption | 198(g/kw.h) |
| Standby power (KW) | 70 | Combustion | Direct Injection |
| Governor | Electronic | Aspiration Type | Turbocharged and air intercooled |
| Alternator Technical Data | |||
| Brand/ Original | Stamford copy/ Stamford original/Marathon/Leroy-Somer | ||
| Alternator Model | HT-60D | Protection | IP23 |
| Alternator Type | Brushless sel-excited | Insulation | Class H |
| Phase / wire | 3-phase& 4 line | Factor | 0.8 |
Control Module Specifications | |||
| Digital Control Module suitable for a wide variety of single, diesel or gas, gen-set applications. Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen and illuminated LEDs. | |||
| The control module gives digital readouts of: | |||
| Generator voltage | Output frequency | Engine hours run | |
| Engine speed | Battery voltage | ||
| The control module has indicators for failure information: | |||
| High water temperature | Failure to start | Battery charger failure | |
| Automatic shutdown occurs under: | |||
| Low engine oil pressure | High engine water temperature | ||
| Over speed/Low speed | Failure to start after three attempts | ||
This is Jiangsu Haut Mechanical Co., Ltd. We manufacturer diesel generator/natural gas generator/Diesel Pump.
SDEC Shangchai Series™ Generators
A new platform to meet the growing needs for right-sized power and reduced emissions.
We manufacture diesel generators and natural gas generators.They power ranges from 10kW to 5000kW,we use well-known diesel engines at home and abroad. They can be equipped with different alternators, such as Stamford, Marathon, Leroy Somer, Engga, and Mecc Alte.
Generators by style
- Open Diesel /Gas Generators
- Silent Diesel Gas Generators
- Trailer type
- Silent trailer type
- Container type
- Grid-connected cabinet type
Generators by Fuel Type
- Diesel Generators
- Natural Gas Generators
- Biogas Generators
- LPG Generators
- Propane Generators
- Gasoline Generators
This series diesel engine is developed and designed according to the advanced heavy-duty engine technology concept, which has the advantages of high reliability, good durability, good fuel economy, small size, large power, large torque, large torque reserve, strong parts versatility and so on.
We use all Brushless / Self excited / Copper alternators, We can customize different voltages and frequencies, such as 50 Hz, 60 Hz, 1500 rpm, 1800 rpm,
SDEC Engine global warranty,1 year or 1000 hours warranty. SDEC inc. provides a full range of components and after-sales service support to customers around the world through a number of dealer outlets.
- Powered by well- known engine made in China and abroad
- Lockable battery isolator switch
- China SmartGen6110, Deepsea DSE6020 or DSE7320 controller with AMF function, ComAp for option
- Battery charger, water jacket preheater, oil heater and double air cleaner etc. for option
- Excitation system: self-excited (PMG for option)
- Integrated wiring design
- Base fuel tank for at least 6-8 hours running ( standard for 500KVA below, option for 500KVA above)
- Vibration isolators between the engine , alternator and base
- Equipped with an industrial muffler
- 50 degree copper radiator
- Drainage for fuel tank
- Complete protection functions and safety labels
- Equipped with circuit breaker (CHINT , ABB for option)
- Auto transfer swtich and Automatic grid connection cabinet for option
- Please click the inquiry to contact us,
- and we will recommend the appropriate configuration for you according to the requirements.
1.What's your power range of diesel generators?
Answer: We can offer the range from 10kva~3000kva.50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
3.What's your payment?
Answer: We accept T/T, L/C,and 30% T/T as the deposit,the balance payment should bepaid before shipping.50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
4.What's your warranty?
Answer: All our products we offer on year warranty or 1000 hours which comes first.50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
6.What's the frequency of diesel generators?
Answer: 50/60HZ
50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
7.Do you have single phase or three phase diesel generators?
Answer: Yes,we have single phase and three phase diesel generators.
50kW Diesel Generator Price 60 kW Diesel Generator 80kVA Diesel Oil Generator Diesel Generators Turkey Open Silent Trailer Type
8. Can you accept OEM?
Answer: Yes, we can accept OEM.
