Basic Info.
Output Type
AC Three Phase
Speed
1500
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Automation Type
Excitation Mode
AC Rotating Exciter
Diesel Engine
Kaipu (Shanghai Kaixun Diesel)
Alternator
Marathon/Stamford/Leroy-Somer/Wanding
Certificate
SGS/TUV/CE/ISO
Fuel Tank
Base Fuel Tank/External Fuel Tank
Silent Box Color
Wanding Blue/Customizable
Controller
Smartgen/Fortrust/Deepsea
Transport Package
Cling Film/Wooden Box/Galvanized Steel Box
Trademark
Wanding Power
Origin
China
HS Code
8502131000
Production Capacity
3000set/Year
Product Description
Product Description
Wanding DCEC Cummins series unit/engine selects the engine produced by Dongfeng Cummins(DCEC Cummins).
Compressor with integral wastegate valve, low-speed response and strong power; integrated design, the number of parts is
nearly 25% less than similar products, lower failure rate, more convenient maintenance; cylinder liner adopts platform textured
rock grinding Design and corrosion-resistant high-strength cast iron piston greatly reduces oil loss, enhances durability, and
has a longer service life.
Product Parameters
| WANDING DCEC CUMMINS series main technical parameter list (T2) | |||||||||||
| DCEC CUMMINS series | Unit power KW/KVA | Diesel model | Diesel power prime/stand-by KW | Number of cylinder | Bore*Stroke | Compression ratio | Minimum Fuel Extinction Rate g/(kW.h) | Diesel engine form | Weight (kg) | Unit Dimensions (mm) | |
| WD-22 | 20/25 | 4B3. 9-G2 | 24/27 | 4 | 102*120 | 18:1 | 205 | Vertical, in-line, water-cooled, four-stroke | 800 | 1800*740*1300 | |
| WD-33 | 30/37.5 | 4BT3.9-G2 | 36/40 | 4 | 102*120 | 18:1 | 205 | 800 | 1900*740*1300 | ||
| WD-50 | 40/50 | 4BTA3.9-G2 | 50/55 | 4 | 102*120 | 17.3:1 | 205 | 800 | 1900*74*1300 | ||
| WD-55 | 50/62.5 | 4BTA3.9-G2 | 58/64 | 4 | 102*120 | 17.3:1 | 205 | 800 | 1900*740*1300 | ||
| WD-80 | 75/93.75 | 6BT5.9-G2 | 86/92 | 6 | 102*120 | 17.3:1 | 205 | 1040 | 2250*800*1300 | ||
| WD-88 | 80/100 | 6BT5.9-G2 | 96/106 | 6 | 102*120 | 17.3:1 | 205 | 1040 | 2250*80S1300 | ||
| WD-100 | 90/112.5 | 6BTA5.9-G2 | 106/116 | 6 | 102*120 | 17.3:1 | 205 | 1060 | 2350*800*1300 | ||
| WD-120 | 100/125 | 6BTAA6.9-G2 | 120/130 | 6 | 102*120 | 17.3:1 | 205 | 1100 | 2450*810*1345 | ||
| WD-160 | 150/187.5 | 6CTA8.3-G2 | 163/180 | 6 | 114*135 | 17.3:1 | 205 | 1450 | 2450*840*1453 | ||
| WD-180 | 160/200 | 6CTAA8.3-G2 | 183/203 | 6 | 114*135 | 18:1 | 205 | 1800 | 2550*960*1492 | ||
| WD-220 | 200/250 | 6LTAA8.9-G2 | 220/240 | 6 | 114*145 | 16.6:1 | 205 | 2000 | 2650*960*1632 | ||
| WD-300 | 275/343.75 | 6LTAA9. 5-G1 | 310/320 | 6 | 116. 5*148 | 16.6:1 | 205 | 2500 | 2850*1100*1800 | ||
| WD-320 | 300/375 | QSZ13-C6 | 328/374 | 6 | 130*163 | 17:1 | 205 | 2600 | 3000*1100*1800 | ||
| WD-320 | 300/375 | 6ZTAA13-G3 | 340/380 | 6 | 130*163 | 17:1 | 205 | 2800 | 3000*1100*1800 | ||
| WD-350 | 320/400 | 6ZTAA13-G2 | 390/415 | 6 | 130*163 | 17:1 | 205 | 3000 | 3100*1200*1800 | ||
| WD-350 | 320/400 | QSZ13-G7 | 367/419 | 6 | 130*163 | 17:1 | 205 | 3000 | 3100*1200*1800 | ||
| WD-400 | 360/450 | QSZ13-G2 | 400/440 | 6 | 130*163 | 17:1 | 205 | 3650 | 3300*1300*1900 | ||
| WD-400 | 360/450 | QSZ13-G5 | 411/470 | 6 | 130*163 | 17:1 | 205 | 3650 | 3300*1300*1900 | ||
| WD-440 | 400/500 | QSZ13-G3 | 450/470 | 6 | 130*163 | 17:1 | 205 | 3850 | 3300*1300*1900 | ||
| WD-450 | 400/500 | QSZ13-G10 | 463/509 | 6 | 130*163 | 17:1 | 205 | 4000 | 3500*1400*1900 | ||
| WD-500 | 450/562.5 | QSZ13-G11 | 513/563. 6 | 6 | 130*163 | 17:1 | 205 | 4000 | 3500*1500*2000 | ||
Optional Alternator
Alternators of brands such as Leroy somer, Marathon, and Stamford are optional, and Chinese-made alternators such as WANDING are also optional.Cover voltage 400V, 690V, 10500V. About Us
